TECNICALL SPECIFICATION
Processor & Architecture
· CPU Options: Typically equipped with either the intell core i5 11th gen or the Core i5-1145G7 (with Intel vPro).
· Core Count: 4 Cores / 8 Threads.
· Clock Speed: 2.40 GHz base frequency, boosting up to 4.20 GHz / 4.40 GHz via Intel Turbo Boost.
· Cache: 8 MB L3 Cache.
· Chipset: Integrated SoC (System on Chip) with the processor.
Memory (RAM) & Storage
· RAM Type: DDR4 SDRAM operating at 3200 MHz.
· RAM Configuration: Configured with 8GB or 16GB (supports Dual-Channel memory performance).
· Expandability: Most x360 830 G8 sub-models utilize 1x SODIMM configuration alongside soldered memory or 2x slots supporting up to 32GB or 64GB max depending on the specific motherboard SKU.
· Storage Type: 256GB PCIe NVMe M.2 Solid State Drive (SSD).
· Storage Speed: High-speed PCIe Gen 3x4 or Gen 4 NVMe lanes.
Display & Graphics
· Screen Size: 13.3-inch diagonal multi-touch screen.
· Panel Type: IPS BrightView or Anti-Glare WLED-backlit display panel.
· Resolution: Full HD (1920 x 1080 pixels).
· Brightness & Color: Configurable options from 250 nits (45% NTSC) up to 400 nits (100% sRGB). Some enterprise layouts include a 1000-nit HP Sure View Reflect privacy screen.
· Graphics Processor: Integrated Intel Iris Xe Graphics (Requires dual-channel RAM setup to achieve full performance; otherwise runs as Intel UHD Graphics).
Battery & Power
· Battery Type: HP Long Life 3-cell, 53 Wh or 56 Wh Li-ion polymer internal battery.
· Charging Capacity: Supports HP Fast Charge (recharges up to 50% in 30 minutes).
· Power Supply: 65W USB Type-C Smart AC Adapter.
Input / Output Ports
· Left Side:
o 2 x SuperSpeed USB Type-A (5Gbps signaling rate, 1 charging port).
o 1 x 3.5mm Headphone/Microphone Combo Audio Jack.
o 1 x Smartcard Reader (Optional configuration).
· Right Side:
o 2 x Thunderbolt 4 with USB4 Type-C (40Gbps signaling rate, Power Delivery, DisplayPort 1.4).
o 1 x HDMI 2.0b video output port.
o 1 x Nano SIM card slot (Only functional on WWAN/LTE cellular enabled models).
