TECNICALL SPECIFICATION
System & Optical Specs
· Image Sensor: Progressive scan CMOS chip.
· Video Resolution: 3MP (2048×1536) / 5MP options.
· Compression Format: H.265 / H.264+ high profile.
· Optical Lens: 4mm fixed focal lens.
· Minimum Illumination: 0.00001 LUX ultra-low light.
Network & Connectivity
· Network Type: 4G LTE Micro-SIM card.
· FDD-LTE Bands: B1, B3, B5, B8.
· TDD-LTE Bands: B34, B38, B39, B40, B41.
· Software Client: V380 Pro mobile application.
· Mobile OS: Android and iOS compatibility.
Power Management
· Solar Panel: 8W monocrystalline silicon module.
· Battery Array: 4x 18650 cells (8000mAh).
· Standby Draw: 5 mAh ultra-low consumption.
· Daytime Operation: 350mA to 400mA draw.
· Night Operation: 500mA to 550mA draw.
PTZ & Detection Capabilities
· Pan Range: 350° to 355° horizontal.
· Tilt Range: 90° vertical rotation.
· Pan Speed: Up to 55° per second.
· Tilt Speed: Up to 40° per second.
· Sensor Array: PIR plus radar dual induction.
· Detection Distance: 0 to 12 meters range.
· Detection Angle: 120° wide coverage field.
Hardware & Environment
· Night Illumination: 8PCS dual-core matrix LEDs.
· IR Distance: Up to 30 meters range.
· White LED Range: Up to 30 meters color.
· Audio Hardware: Built-in mic and speaker.
· Storage Limit: 128GB MicroSD card maximum.
· Enclosure Rating: IP65 / IP66 weatherproof enclosure.
· Temperature Limits: -30°C to +50°C environment.
